SLW 03PA

Piezo vandal-proof toilet flushing unit with distant control, 24 V DC

Characteristics

  • with second piezo button for remote flush for disabled people
  • vandal-proof
  • suitable for prison
  • special vandal-proof stainless steel cover, thickness 3 mm, safety screws
  • toilet flushing unit for a pressure water from water distribution, isn´t possible to use it for toilet with tank
  • water flows after soft push of the piezo button
  • adjustable flushing time 0,5 - 15,5 s, standard 8 s
  • automatic hygiene flush after each 8 use of toilet and after 24 hours non-use
  • electromagnetic valve with a possibility to regulate rate of flow, possibility to flush a toilet by turn of coil of the electromagnetic valve (f.e. in the case of electricity blackout)
  • parameters adjustment by remote control SLD 04
Order number 14036
Code SLW 03PA

Supply specification

SLW 03PA - Supply No. 14036 - stainless steel cover with piezo electronics, stainless steel mounting box with brass screw coupling and electromagnetic valve, outlet fitting with rubber seal, torx screws (4 pcs.), stainless steel cover with piezo electronics for remote flushing, plastic mounting box, torx screws (2 pcs.), connecting cable (2500 mm), connectors

Technical information

Stainless steel cover dimension: 160 x 170 x 3 mm
Mounting box dimension: 145 x 155 x 100 mm
Stainless steel cover dimension for remote flush: 85 x 90 x 3 mm
Operating voltage: 24 V DC
Recommended flow pressure: 0,15 - 0,6 MPa
Rate of flow: 60 l/min. (inf. data)
Water inlet: male thread G 1″
Water outlet: inlet fitting with a rubber sealing
