SLU 39PBX
Set of stainless steel piezo wall-mounted washbasin tap for subsequent mounting, brushed, 6 V
Characteristics
- economical aerator, rate of flow 6 l/min
- hygienic flush
- lead free
- is destined for installation into the wall (necessary to use installation set SLA 52B)
- is destined for installation into the sheets with a max. thickness of 5 mm
- is destined for cold or premixed water
- index X - brushed finish
- water flows after soft push of the piezo button
- water stops flowing after adjustable flowing time (can be set in 2 - 62 s), standard 10 s
- water could be stopped by follow-up soft push of piezo button
- monitoring of battery capacity
- parameter adjustment using by the remote control SLD 04
- Order number: 03395
I am interested in more information:
Supply specification
SLU 39PBX - Supply No. 03395 - faucet, piezo electronics, electromagnetic valve (1 pcs.), 4 psc. AA alkaline batteries 1,5 V, 2700 mAh with battery case
Technical information
| Material: | stainless steel |
| Temperature regulation: | for cold or premixed water |
| Power supply: | battery operated |
| Control: | piezo |
| Operating voltage: | 6 V |
| Battery life: | 4 pcs. AA alkaline batteries AA, 1,5 V, 2700 mAh (approx. 2 years (100 uses per day) |
| Recommended flow pressure: | 0,1 - 0,6 MPa |
| Rate of flow: | 6 l/min. (inf. data) |
| Water inlet: | male thread G 1/2“ |
Downloads
- Mounting instructions (1.39 MB)
- Catalogue list (243.52 kB)
- 2D Drawing (124.51 kB)
