SLUN 75E
Vandal-proof stainless steel automatic recessed washbasin, for cold or premixed water, 24 V DC
While stocks last
Characteristics
- economical aerator, rate of flow 6 l/min
- hygienic flush
- vandal-proof
- suitable for prison
- stainless steel recessed washbasin with integrated automatic water outlet
- SLUN 75E - is destined for cold a premixed water
- rear assembling by screws (M10, length 190 mm) from the service room
- water is flowing as long as hands are in the active range
- water stops flowing after removal of hands from the active range of sensor after adjustable time delay (can be set in range 0,25 - 7,75 s)
- function of automatic water stop after 5 minut of continuous flow
- START/STOP program
- parameter adjustment using by the remote control SLD 03
- material AISI - 304
- brushed finish
- Order number: 93751
I am interested in more information:
Supply specification
SLUN 75E - Supply No. 93751 - stainless steel washbasin with integrated water outlet and electronics, electromagnetic valve (1 pc.), connecting hoses, angle valve with filter (1 pc.), siphon, mounting set
Technical information
| Temperature regulation: | for cold or premixed water |
| Power supply: | 24V DC |
| Installation: | recessed into the wall |
| Category: | washbasin |
| Control: | infra-red |
| Operating voltage: | 24 V DC |
| Recommended flow pressure: | 0,1 - 0,6 MPa |
| Rate of flow: | 12 l/min. (inf. data) |
| Water inlet: | male thread G 1/2“ |
Downloads
- Mounting instructions (1.6 MB)
- Catalogue list (207.55 kB)
- 2D Drawing (284.02 kB)
