SLS 01PBA

Piezo shower control for cold or premixed water, with TORX screws, 6 V

Characteristics

  • hygienic flush
  • vandal-proof
  • suitable for a prison
  • special vandal-proof stainless steel cover, thickness 3 mm, safety screws
  • is destined for cold or premixed water
  • water flows after soft push of the piezo button
  • water stops flowing after adjustable flowing time (can be set in 10 s - 310 s), standard 120 s
  • water could be stopped by follow-up soft push of piezo button
  • monitoring of battery capacity (for models with index B)
  • parameter adjustment using by the remote control SLD 04
  • Order number: 12018
  • EAN: 8591385120183
I am interested in more information:

Supply specification

SLS 01PBA - Supply No. 12018 - stainless steel cover with electronics, plastic mounting box with brass screw coupling,
electromagnetic valve and ball valve, 4x torx screw, 4 pcs. AA alkaline batteries 1,5 V, 2700 mAh (SLS 01PBA), waterproofing foil

Technical information

Stainless steel cover dimension 170 x 170 x 10 mm
Mounting box dimension 140 x 140 x 75 mm
Operating voltage 6 V
Battery life 4 pcs. AA alkaline batteries AA, 1,5 V, 2700 mAh approx. 2 years (100 uses per day)
Recommended flow pressure 0,1 - 0,6 MPa
Rate of flow 12 l/min. (inf. data)
Water inlet male thread G 3/4“
Water outlet male thread G 3/4“

Downloads

Accessories

Vandal-proof shower head
Vandal-proof shower head, adjustable…
Vandal-proof shower head
Set of 4 pcs. of alcaline batteries
Vandal-proof shower head
Vandal-proof shower head
Remote control for an adjustment of…
Thermostatic mixing valve 3/4" (28l/min)
Thermostatic mixing valve 1/2” (20l/min)
Thermostatic mixing valve 3/4" (43l/min…
Thermostatic mixing valve 1" (53l/min.)
Thermostatic mixing valve 5/4" (82l/min…
Thermostatic mixing valve 6/4" (155l…
