SLUN 70P
Vandal-proof stainless steel multifunctional washbasin, front mounting
Characteristics
- hygienic flush
- vandal-proof
- suitable for prison
- stainless steel recessed multiple washbasin with integrated piezo electronics for soap dispenser, water outlet and hand dryer in one
- rear assembling through the service hatch
- water flows after soft push of the piezo button
- liquid soap refilling from the service hatch
- parameter adjustment using by the remote control SLD 07
- material AISI - 304
- brushed finish
- Order number: 73703
I am interested in more information:
Supply specification
SLUN 70P - Supply No. 73703 - stainless steel multiple washbasin with piezo electronics, integrated soap dispenser, water outlet and hand dryer, siphon, mounting set, flexible cabel with plug for wall socket 230 V/50 Hz
Technical information
| Temperature regulation: | for cold or premixed water |
| Installation: | recessed into the wall |
| Category: | washbasin |
| Control: | piezo |
| Operating voltage: | 230 V AC/50 Hz |
| Recommended flow pressure: | 0,1 - 0,6 МPa |
| Water flow: | 6 l/min. (inf. data) |
| Water inlet: | male thread G 1/2“ |
Downloads
- Mounting instructions (4.15 MB)
- Catalogue list (297.65 kB)
- 2D Drawing (1.02 MB)
