SLU 68
Hybrid Sink Faucet, 24 V DC
New product
Characteristics
- includes Bluetooth control (paid Sanela Control app available for download)
- hygienic flush
- swivel spout
- pull-out shower
Hybrid design:
Water activation by touchless sensor:
- responds to the presence of a hand in the sensing zone by immediately starting the water
- a second approach of the hand stops the water
- temperature adjustment by thermostat under the sink
- the product includes a socket power supply
Water activation by lever:
- manual control of temperature and water flow by lever
- Order number: 03680
- EAN: 8591385036804
I am interested in more information:
Supply specification
SLU 68 - Supply No. 03680 - Faucet with temperature control, electronics including Bluetooth module, solenoid valve, thermostatic valve, connecting hose, angle valve with filter and check valve (2 pcs), 230 V AC/24 V DC socket power supply
Technical information
| Dimensions: | 273 x 485 mm |
| Weight: | 2,46 kg |
| Operating voltage: | 24 V DC |
| Power input: | 3 W |
| Active range: | START/STOP program 0,05 - 0,15 m |
| Recommended flow pressure: | 0,1 - 0,6 MPa |
| Rate of flow: | 15 l/min |
| Water inlet: | male thread G 1/2“ |
Downloads
- Mounting instructions (9.11 MB)
- Catalogue list (166.46 kB)
- 2D Drawing (117.32 kB)
